FREEION Carbonated Soft Drink Filling Machine is designed for safe, accurate, and high-speed filling of carbonated beverages such as soft drinks, soda, sparkling water, and flavoured fizzy drinks.
The machine ensures maximum CO₂ retention, minimum foaming, and consistent fill level, even at high production speeds.
The system combines rinsing, filling, and capping in one compact and hygienic monoblock, making it ideal for modern beverage plants.
| Parameter | Specification |
|---|---|
| Machine Type | Rinsing – Counter Pressure Filling – Capping |
| Application | Carbonated Soft Drinks, Soda, Sparkling Water |
| Bottle Material | PET / Glass |
| Filling Method | Counter Pressure Filling |
| Bottle Size Range | 200 ml – 2000 ml |
| Number of Filling Valves | 6 – 72 |
| Production Capacity | Up to 36,000 BPH |
| Cap Type | Screw Cap / PCO / Crown Cap |
| CO₂ Retention | High, with Controlled Pressure |
| Product Contact Parts | SS316L |
| Control System | PLC with Touch Screen HMI |
| CIP System | Compatible |
| Power Supply | 415 V, 50 Hz |
| Machine Structure | SS304 |
| Specifications can be customised as per customer requirement. | |
| No. | Model (R/F/C) | 200 ml | 500 ml | 1000 ml | 2000 ml |
|---|---|---|---|---|---|
| 01 | 6/6/3 | 40 BPM | 30 BPM | 25 BPM | 12 BPM |
| 02 | 8/8/4 | 60 BPM | 50 BPM | 35 BPM | 18 BPM |
| 03 | 10/10/5 | 75 BPM | 65 BPM | 45 BPM | 22 BPM |
| 04 | 12/12/6 | 95 BPM | 75 BPM | 55 BPM | 28 BPM |
| 05 | 18/18/6 | 140 BPM | 120 BPM | 85 BPM | 42 BPM |
| 06 | 24/24/8 | 190 BPM | 170 BPM | 115 BPM | 58 BPM |
| 07 | 30/30/10 | 240 BPM | 190 BPM | 145 BPM | 72 BPM |
| 08 | 40/40/10 | 300 BPM | 240 BPM | 190 BPM | 95 BPM |
FREEION CSD fillers are specially developed for carbonated beverages.
FREEION Juice Filling Machines are engineered to minimize Total Cost of Ownership (TCO).
FREEION CSD fillers use advanced counter-pressure filling technology specially designed for carbonated beverages.
Empty Bottles Enter the Rinsing Section Where They Are Cleaned Using Treated Water. Bottles Are Then Transferred to the Filling Section Where Juice is Filled Accurately Under Hygienic Conditions.After Filling, Bottles Move Automatically to the Capping Section for Secure Sealing Before Transferring to Labelling, Shrink Wrapping, Carton Packing, and Final Dispatch.
Proven Counter-Pressure Filling Technology
High Carbonation Retention & Product Quality
Reliable High-Speed Operation
Hygienic Beverage Industry Design
Easy Integration with Mixers, Carbonators & Packaging Lines
Low Operating Cost & Long Service Life
Strong Technical & After-Sales Support
