FREEION ENGINEERING Pvt. Ltd. offers advanced PET Bottle Water Filling Lines with integrated Rinser–Filler–Capper (RFC) technology designed for hygienic, high-speed, and efficient bottled water production.
FREEION’s PET Filler is engineered with advanced filling technology that combines superior hygiene standards, operational flexibility, sustainability, and high-performance production in a compact and efficient system. Designed for packaged drinking water and still beverage applications, our RFC machines ensure outstanding product quality with the lowest Total Cost of Ownership (TCO).
With configurations ranging from 6 to 70 filling valves, FREEION PET Fillers support a wide range of bottle sizes from 200 ml to 20 litres and production speeds up to 42,000 bottles per hour.
| Specification | Details |
|---|---|
| Machine Type | Rinser – Filler – Capper (RFC) Combo |
| Application | Packaged Drinking Water / Mineral Water |
| Bottle Type | PET Bottles |
| Bottle Size Range | 200 ml to 2000 ml |
| Filling System | Gravity / Level Filling |
| Rinsing System | Inverted Bottle Rinsing |
| Capping Type | Plastic Screw Cap |
| Production Capacity | 30 BPM to 240 BPM |
| Construction Material | SS304 / SS316 |
| Control System | PLC with Touch Screen HMI |
| Power Supply | 415V / 50Hz / 3 Phase |
| Air Requirement | 6–8 Bar |
| Operation | Fully Automatic |
| Specifications can be customized as per customer requirements. | |
| No. | Model (R/F/C) | 200 ml | 500 ml | 1000 ml | 2000 ml |
|---|---|---|---|---|---|
| 01 | 6/6/3 | 50 BPM | 40 BPM | 30 BPM | 15 BPM |
| 02 | 8/8/4 | 70 BPM | 60 BPM | 40 BPM | 20 BPM |
| 03 | 10/10/5 | 80 BPM | 70 BPM | 50 BPM | 25 BPM |
| 04 | 12/12/6 | 100 BPM | 80 BPM | 60 BPM | 30 BPM |
| 05 | 18/18/6 | 150 BPM | 125 BPM | 90 BPM | 45 BPM |
| 06 | 24/24/8 | 200 BPM | 180 BPM | 120 BPM | 60 BPM |
| 07 | 24/30/8 | 220 BPM | 180 BPM | 140 BPM | 70 BPM |
| 08 | 30/30/10 | 250 BPM | 200 BPM | 150 BPM | 75 BPM |
| 09 | 40/40/10 | 320 BPM | 250 BPM | 200 BPM | 100 BPM |
| 10 | 40/50/12 | 400 BPM | 325 BPM | 250 BPM | 125 BPM |
| 11 | 40/60/14 | 500 BPM | 400 BPM | 300 BPM | 150 BPM |
| 12 | 50/70/14 | 560 BPM | 450 BPM | 350 BPM | 175 BPM |
| 13 | 60/80/20 | 640 BPM | 500 BPM | 400 BPM | 200 BPM |
FREEION PET Fillers use advanced gravity contactless filling technology for precise and hygienic operation.
FREEION PET Fillers use internationally proven filling solutions for maximum product safety and premium quality.
FREEION RFC systems are designed to minimize energy, water, and maintenance costs.
Empty PET bottles enter the rinsing section where they are internally cleaned using treated water. Bottles are then transferred automatically to the filling section where precise and hygienic filling is carried out using gravity filling technology.
Filled bottles move to the capping section where caps are automatically placed and sealed before bottles are discharged through conveyors for labeling and packaging operations.
Our advanced Water Treatment Systems are engineered to deliver superior water purification performance for packaged drinking water and beverage applications.
The treatment process is customized according to feed water quality and final product requirements to ensure safe, clean, and consistent water quality.
Global-Style Hygienic Design
High Filling Accuracy
Reliable Leak-Proof Capping
Compact & Space-Saving Structure
Energy-Efficient Operation
Low Total Cost of Ownership
Reliable Performance & Long Service Life
Strong Technical & After-Sales Support
