FREEION Glass Bottle Water Filling Machine is engineered for hygienic, accurate, and reliable filling of packaged drinking water, mineral water, and still water in glass bottles.
The machine combines rinsing, filling, and capping in one compact monoblock system, ensuring smooth bottle handling, high hygiene standards, and stable high-speed production. Designed for premium bottled water applications, the system delivers excellent product quality, low operating cost, and reliable long-term performance.
FREEION glass bottle fillers are suitable for small, medium, and large water bottling plants.
| Parameter | Specification |
|---|---|
| Machine Type | Glass Bottle Water Filling Machine |
| Filling Method | Gravity Filling |
| Application | Packaged Drinking Water / Mineral Water |
| Bottle Material | Glass Bottles |
| Bottle Size Range | 200 ml – 2000 ml |
| Production Capacity | Up to 36,000 BPH |
| Cap Type | Crown Cap / Screw Cap |
| Product Contact Parts | SS AISI 316L |
| Machine Structure | SS 304 |
| Control System | PLC with Touch Screen HMI |
| Rinsing System | Inverted Bottle Rinsing |
| CIP Compatibility | Yes |
| Power Supply | 415 V / 50 Hz / 3 Phase |
| Machine Operation | Fully Automatic |
| Maintenance | Low |
| No. | Model (R/F/C) | 250 ml | 500 ml | 1000 ml |
|---|---|---|---|---|
| 01 | 12/12/6 | 60 BPM | 50 BPM | 30 BPM |
| 02 | 18/18/6 | 100 BPM | 80 BPM | 50 BPM |
| 03 | 24/24/8 | 150 BPM | 120 BPM | 70 BPM |
| 04 | 30/30/10 | 220 BPM | 180 BPM | 100 BPM |
| 05 | 40/40/10 | 300 BPM | 250 BPM | 150 BPM |
| 06 | 50/50/12 | 400 BPM | 320 BPM | 180 BPM |
| 07 | 60/60/15 | 500 BPM | 400 BPM | 220 BPM |
FREEION water fillers are designed for safe and hygienic water bottling operations.
Features:
Benefits:
The compact monoblock machine combines rinsing, filling, and capping in one unit.
Bottle Rinser
Water Filler
Bottle Capper
Benefits:
FREEION machines are specially designed for safe glass bottle movement.
Features:
Benefits:
FREEION filling systems ensure reliable performance even during continuous operation.
Features:
Benefits:
Designed for user-friendly operation and fast format changes.
Features:
Benefits:
Lower maintenance effort
FREEION machines are designed to minimise operating cost and utility consumption.
Energy Saving:
Maintenance Saving:
Water Saving:
Hygienic and reliable filling solution
Accurate filling and leak-proof capping
Gentle handling for glass bottles
Stable high-speed production performance
Energy-efficient and low maintenance
Easy integration with packaging systems
Reliable performance for Indian operating conditions
Strong technical and after-sales support
